SDI Video Outputs
2 x SDI Video Outputs.
Blackmagic Mini Converter Analog to SDI 2
$ 269.00 - Sold Out
Blackmagic Mini Converter Analog to SDI 2
$ 269.00 - Sold Out
Blackmagic Mini Converter Analog to SDI 2
Blackmagic SKU: BMD-CONVMAAS2 | Helix SKU: BMDCONVMAAS2
Overview
The ideal solution for converting analog component, s-video, NTSC/PAL composite to SDI video. Audio can be embedded from balanced analog or AES/EBU inputs. Now you can convert analog devices such as Betacam SP, VHS, set top boxes, gaming consoles and HDV cameras to incredible quality SD/HD-SDI video.
Specifications
Connections
Analog Video Inputs
NTSC, PAL, S‑Video and Component SD/HD input.
Analog Audio Inputs
2 channels of balanced analog audio.
Digital Audio Inputs
2 channels of balanced AES/EBU audio.
Multi Rate Support
Auto detection of SD or HD.
Updates and Configuration
Via USB 2.0 high speed. (480 Mb/s)
Reclocking
Yes
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, ITU‑R BT.656 and ITU‑R BT.601.
SDI Video Rates
SDI video connections are switchable between standard definition and high definition.
SDI Video Sampling
4:2:2
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2
SDI Color Space
YUV
SDI Auto Switching
Automatically follows format of analog input.
Analog Video Standards
525i29.97 NTSC, 625i25 PAL
Analog Color Space
YUV
Analog Color Precision
4:2:2
Software
Software Control
Mac™ and Windows™ software upgrade via USB.
Internal Software Upgrade
Via included updater application.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
6.50 Watts
Operational Voltage Range
12 ‑ 31V DC
Settings Control
Mini Switches or USB software.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Physical Specifications
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non‑condensing
What's Included
Mini Converter Analog to SDI
12V AC adapter with international socket adapters for all countries.
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter Audio to SDI
$ 265.00 - Sold Out
Blackmagic Mini Converter Audio to SDI
$ 265.00 - Sold Out
Blackmagic Mini Converter Audio to SDI
Blackmagic SKU: BMD-CONVMCAUDS2 | Helix SKU: BMDCONVMCAUDS2
Overview
Embed audio into any SDI source in SD and HD formats up to 1080p60! Audio is input as balanced analog or AES/EBU using ¼ inch connectors from equipment such as mixers and analog decks. Mini Converter Audio to SDI is the ideal SD/HD SDI audio embedder for when you don’t need the cost of the Ultra HD model!
Specifications
Connections
SDI Video Inputs
1 x SD, HD or 3G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
SDI Video Outputs
1 x Embedded SDI Output.
Analog Audio Inputs
4 channels of balanced analog audio.
Digital Audio Inputs
8 channels of balanced AES/EBU audio.
SDI Redundant Input
Automatically switches over if main SDI input is lost.
Multi Rate Support
Auto detection of SD, HD or 3G‑SDI.
Updates and Configuration
Via USB 2.0 high speed. (480 Mb/s)
Reclocking
Yes
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M‑B, SMPTE 425M, ITU‑R BT.656, ITU‑R BT.601, SMPTE ST‑2036
SDI Video Rates
SDI video connections are switchable between standard definition and high definition.
SDI Video Sampling
4:2:2, 4:4:4
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2, 4:4:4
SDI Color Space
YUV, RGB
SDI Auto Switching
Automatically selects between SD, HD, and 3G‑SDI.
Software
Software Control
Mac™ and Windows™ software upgrade via USB.
Internal Software Upgrade
Via included updater application.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Settings Control
Mini Switches or USB software.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
8.40 Watts
Operational Voltage Range
12V DC
Physical Specifications
Environmental Specifications
Operating Temperature
0° to 40° C (32° to 104° F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non‑condensing
What's Included
Mini Converter Audio to SDI
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter Audio to SDI 4K
$ 389.00 - Sold Out
Blackmagic Mini Converter Audio to SDI 4K
$ 389.00 - Sold Out
Blackmagic Mini Converter Audio to SDI 4K
Blackmagic SKU: BMD-CONVMCAUDS4K | Helix SKU: BMDCONVMCAUDS4K
Overview
Mini Converter Audio to SDI 4K includes everything you need to embed 4 channels of analog audio or 8 channels of AES/EBU digital audio into any SDI video connection. Now you can embed professional audio from devices such as audio mixers and analog decks into SDI video connections for use with SDI routers and decks or to add extra audio channels to video converters!
Specifications
Connections
SDI Video Inputs
1 x SD, HD or 6G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
SDI Video Outputs
1 x Embedded SDI Output.
Analog Audio Inputs
4 channels of professional balanced analog audio with standard 1/4 inch jack connections.
Digital Audio Inputs
8 channels of professional balanced digital with standard 1/4 inch jack connections.
SDI Redundant Input
Automatically switches over if main SDI input is lost.
Multi Rate Support
Auto detection SD, HD or 6G‑SDI.
Updates and Configuration
Via USB 2.0 high speed. (480 Mb/s)
Reclocking
Yes
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M‑B, SMPTE 425M, SMPTE ST-2036, SMPTE ST‑2081, ITU‑R BT.656 and ITU‑R BT.601.
SDI Video Rates
SDI video connections are switchable between standard definition and high definition.
SDI Video Sampling
4:2:2, 4:4:4
SDI Audio Sampling
Television standard sample rate of 48kHz and 24‑bit.
SDI Color Precision
4:2:2, 4:4:4
SDI Color Space
YUV, RGB
SDI Auto Switching
Automatically selects between SD, HD, 3G and 6G‑SDI.
Software
Software Control
Mac™ and Windows™ software upgrade via USB.
Internal Software Upgrade
Via included updater application.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Settings Control
Mini Switches or USB software.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
8.40 Watts
Operational Voltage Range
12 ‑ 31V DC
Physical Specifications
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non‑condensing
What's Included
Mini Converter Audio to SDI 4K
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter HDMI to SDI 6G
$ 185.00 - Sold Out
Blackmagic Mini Converter HDMI to SDI 6G
$ 185.00 - Sold Out
Blackmagic Mini Converter HDMI to SDI 6G
Blackmagic SKU: BMD-CONVMBHS24K6G | Helix SKU: BMDCONVMBHS24K6G
Overview
Mini Converter HDMI to SDI 6G includes everything you need to convert from HDMI devices to SDI video in SD, HD and Ultra HD video formats. With independent audio connections you can also embed SDI audio from HDMI, AES/EBU or balanced analog audio inputs. Mini Converter HDMI to SDI 6G is the perfect solution to convert HDMI consumer cameras or computers to broadcast quality SDI!
Specifications
Connections
SDI Video Outputs
2 x SDI Video Outputs. Automatically matches the SD, HD and 6G‑SDI HDMI video input.
HDMI Video Inputs
HDMI type A in
Analog Audio Inputs
2 channels of professional balanced analog audio with standard 1/4 inch jack connections.
Digital Audio Inputs
4 channels of AES/EBU digital audio.
Multi Rate Support
Auto detection of SD, HD or 6G‑SDI.
Updates and Configuration
USB
Reclocking
Yes
Standards
SD Video Standards
625i25 PAL, 525i29.97 NTSC
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M Level A or Level B, SMPTE ST‑2081, ITU‑R BT.656 and ITU‑R BT.601.
SDI Video Rates
SDI video connections are switchable between SD, HD, Ultra HD and DCI 4K.
SDI Video Sampling
4:2:2
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2
SDI Color Space
YUV
SDI Auto Switching
Automatically detects SD, HD or 6G‑SDI.
HDMI Video Standards
625i25 PAL, 525i29.97 NTSC, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60, 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
HDMI Color Space
YUV and RGB
HDMI Color Precision
4:2:2 and 4:4:4
Copy Protection
HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
Format Conversion
HD down conversion
Software
Software Control
Mac OS and Windows software upgrade via USB.
Internal Software Upgrade
Via included updater application.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Settings Control
Mini Switches or USB software.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
4.44 Watts
Operational Voltage Range
12 ‑ 18V DC
Physical Specifications
Environmental Specifications
Operating Temperature
0° to 40° C (32° to 104° F)
Storage Temperature
-20° to 45° C (‑4° to 113° F)
Relative Humidity
0% to 90% non‑condensing
What's Included
Mini Converter HDMI to SDI 6G
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter Optical Fiber 12G
$ 199.00 - Sold Out
Blackmagic Mini Converter Optical Fiber 12G
$ 199.00 - Sold Out
Blackmagic Mini Converter Optical Fiber 12G
Blackmagic SKU: BMD-CONVMOF12G | Helix SKU: BMDCONVMOF12G
Overview
Mini Converter Optical Fiber 12G converts SDI to optical fiber and optical fiber to SDI in both directions at the same time, you can even have different video standards going in each direction! The 12G‑SDI connections are multi rate, which makes it compatible with all SD, HD and Ultra HD formats and equipment up to 2160p60, including Level A and B devices. You can install any standard 3G, 6G or 12G‑SDI SFP optical fiber module so you can send SDI using the same low cost optical fiber cables that are commonly used for computer networks.
Specifications
Connections
SDI Video Inputs
1 x SD, HD and 12G‑SDI Video and 1 x Optical Fiber Input.
SDI Video Outputs
Automatically matches the SD, HD and 12G‑SDI video input on the Optical Fiber.
Optical Fiber Connection (optional)
1x SMPTE optical fiber SFP socket.
Optical fiber SFP module sold separately.
Optical Fiber Video Inputs
1 x 10 bit SD/HD/12G‑SDI switchable.
Optical Fiber Video Outputs
Automatically matches the SD, HD and 12G‑SDI video input.
Optical Fiber Audio Inputs
16 channel embedded.
Optical Fiber Audio Outputs
16 channel embedded.
Multi Rate Support
Auto detection of SD, HD or 12G‑SDI.
Reclocking
Yes
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M‑B, SMPTE 425M, SMPTE 424M‑B, SMPTE ST‑2081, ITU‑R BT.656, ITU‑R BT.601 and SMPTE 297M for Optical Fiber SDI.
SDI Video Rates
SDI video connections are switchable between SD, HD, Ultra HD and DCI 4K.
SDI Video Sampling
4:2:2 and 4:4:4
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2 and 4:4:4
SDI Color Space
YUV and RGB
SDI Auto Switching
Automatically detects SD, HD or 12G‑SDI.
ASI Support
Yes
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Settings Control
No user controls.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
2 Watts
Operational Voltage Range
6 - 36V DC
Physical Specifications
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
What's Included
Mini Converter Optical Fiber 12G
+12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter SDI Distribution
$ 199.00 - Sold Out
Blackmagic Mini Converter SDI Distribution
$ 199.00 - Sold Out
Blackmagic Mini Converter SDI Distribution
Blackmagic SKU: BMD-CONVMSDIDA | Helix SKU: BMDCONVMSDIDA
Overview
Now you can distribute a single SD or HD‑SDI connection to up to 8 different SDI outputs at the same time! You get a true 3G‑SDI design with fully re‑clocked outputs and automatic switching between all SD and HD formats up to 1080p60. You also get support for all ASI, ancillary and embedded audio formats. Mini Converter SDI Distribution is the perfect SD/HD SDI distribution converter for when you don’t need the cost of the Ultra HD model!
Specifications
Connections
SDI Video Inputs
1 x SDI Video Input. Switchable between SD, HD and 3G‑SDI.
SDI Video Outputs
8 outputs automatically match the SDI video input.
Multi Rate Support
Auto detection of SD, HD or 3G‑SDI.
Reclocking
Yes
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080PsF23.98, 1080p24, 1080PsF24, 1080p25, 1080PsF25, 1080p29.97, 1080PsF29.97, 1080p30, 1080PsF30, 1080p50, 1080p59.94, 1080p60.
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M‑B and SMPTE 425M
SDI Video Rates
SDI video connections are switchable between SD, HD, and DCI 2K.
SDI Video Sampling
4:2:2 and 4:4:4
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2 and 4:4:4
SDI Color Space
YUV and RGB
SDI Auto Switching
Automatically detects SD, HD or 3G‑SDI.
ASI Support
Yes
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
4.80 Watts
Operational Voltage Range
12 ‑ 31V DC
Physical Specifications
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non‑condensing
What's Included
Mini Converter SDI Distribution
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter SDI Distribution 4K
$ 375.00 - Sold Out
Blackmagic Mini Converter SDI Distribution 4K
$ 375.00 - Sold Out
Blackmagic Mini Converter SDI Distribution 4K
Blackmagic SKU: BMD-CONVMSDIDA4K | Helix SKU: BMDCONVMSDIDA4K
Overview
When you need to connect to multiple SDI devices, then Mini Converter SDI Distribution 4K is the perfect solution! Connect a single SDI source to 8 re‑clocked SDI outputs with automatic switching between all SD‑SDI, HD‑SDI, 3G‑SDI and 6G‑SDI video formats, plus all ASI, ancillary and embedded audio formats.
Connections
SDI Video Inputs
Switchable between SD, HD and 6G‑SDI.
Reclocking
Yes
SDI Video Outputs
8 outputs automatically match the SDI video input.
Multi Rate Support
Auto detection of SD, HD or 6G‑SDI.
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080PsF23.98, 1080p24, 1080PsF24, 1080p25, 1080PsF25, 1080p29.97, 1080PsF29.97, 1080p30, 1080PsF30, 1080p50, 1080p59.94, 1080p60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M‑B, SMPTE 425M, SMPTE ST‑2081
SDI Video Rates
SDI video connections are switchable between SD, HD, Ultra HD and DCI 4K.
SDI Video Sampling
4:2:2 and 4:4:4
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2 and 4:4:4
SDI Color Space
YUV and RGB
SDI Auto Switching
Automatically detects SD, HD or 6G‑SDI.
ASI Support
Yes
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
4.80 Watts
Operational Voltage Range
12 ‑ 31V DC
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Specifications
Physical Specifications
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
What's Included
Mini Converter SDI Distribution 4K
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter SDI to Analog
$ 259.00 - Sold Out
Blackmagic Mini Converter SDI to Analog
$ 259.00 - Sold Out
Blackmagic Mini Converter SDI to Analog
Blackmagic SKU: BMD-CONVMASA | Helix SKU: BMDCONVMASA
Overview
The perfect way to convert from SD and HD‑SDI to analog component, s‑video or NTSC/PAL composite. Mini Converter SDI to analog supports all SD and HD input formats up to 1080p30 and includes a down converter for when you need to convert from HD to standard definition analog formats such as s‑video and composite. Audio can be de‑embedded to balanced analog or AES/EBU. Mini Converter SDI to Analog is ideal for converting to older analog equipment when you don’t need the extra cost of the 6G‑SDI 4K model.
Specifications
Connections
SDI Video Inputs
1 x SD, HD or 1.5G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
SDI Video Outputs
1 x SDI Loop Output.
SDI Rates
270Mb, 1.5G
Analog Video Outputs
NTSC, PAL, S‑Video and component SD/HD from 1.5G‑SDI input.
Analog Audio Outputs
2 channels of professional balanced analog audio with standard 1/4 inch jack connections.
Digital Audio Outputs
2 channels of balanced AES/EBU audio.
SDI Redundant Input
Automatically switches over if main SDI input is lost.
Multi Rate Support
Auto detection of SD, HD or 1.5G‑SDI.
Updates and Configuration
USB
Reclocking
Yes
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
SDI Compliance
SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M‑B, SMPTE 425M, ITU‑R BT.656 and ITU‑R BT.601.
SDI Video Rates
SDI video connections are switchable between SD and HD.
SDI Video Sampling
4:2:2
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2
SDI Color Space
YUV
SDI Auto Switching
Auto detection of SD, HD or 3G‑SDI.
Analog Video Standards
525i29.97 NTSC, 625i25 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080i50, 1080i59.94, 1080i60
Analog Color Space
YUV
Analog Color Precision
4:2:2
Format Conversion
HD to SD down converter.
Software
Software Control
Mac™ and Windows™ software upgrade via USB.
Internal Software Upgrade
Via included updater application.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Settings Control
Mini Switches or USB software.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
8.04 Watts
Operational Voltage Range
12 ‑ 15V DC
Physical Specifications
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
What's Included
Mini Converter SDI to Analog
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter SDI to Analog 4K
$ 389.00 - Sold Out
Blackmagic Mini Converter SDI to Analog 4K
$ 389.00 - Sold Out
Blackmagic Mini Converter SDI to Analog 4K
Blackmagic SKU: BMD-CONVMASA4K | Helix SKU: BMDCONVMASA4K
Overview
Mini Converter SDI to Analog 4K includes everything you need to convert from SD, HD, 3G and 6G‑SDI video to analog in HD/SD component, NTSC and PAL video. The built in down converter means you can even connect Ultra HD sources to component video in SD or HD as well as NTSC and PAL video! Easily connect any analog equipment such as Betacam SP, VHS, and video monitors!
Specifications
Connections
SDI Video Inputs
1 x SD, HD or 6G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
SDI Video Outputs
1 x SDI Video Loop Output.
Analog Video Outputs
NTSC, PAL, S‑Video and component SD/HD from 6G‑SDI input.
Analog Audio Outputs
2 channels of professional balanced analog audio with standard 1/4 inch jack connections.
Digital Audio Outputs
2 channels of professional balanced digital with standard 1/4 inch jack connections.
SDI Redundant Input
Automatically switches over if main SDI input is lost.
Multi Rate Support
Auto detection of SD, HD or 6G‑SDI.
Updates and Configuration
USB
Reclocking
Yes
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
SDI Compliance
SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M‑B, SMPTE 425M, SMPTE ST‑2081, ITU‑R BT.656, ITU‑R BT.601.
SDI Video Rates
SDI video connections are switchable between SD, HD, Ultra HD and DCI 4K.
SDI Video Sampling
4:2:2
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2
SDI Color Space
YUV
SDI Auto Switching
Automatically detects SD, HD or 6G‑SDI.
Analog Format Support
525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080i50, 1080i59.94, 1080i60
Analog Color Space
YUV
Analog Color Precision
4:2:2
Format Conversion
HD down conversion
Software
Software Control
Mac™ and Windows™ software upgrade via USB.
Internal Software Upgrade
Via included updater application.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Settings Control
Mini Switches or USB software.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
8.04 Watts
Operational Voltage Range
12 ‑ 31V DC
Physical Specifications
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non‑condensing
What's Included
Mini Converter SDI to Analog 4K
Software CD
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter SDI to Audio 4K
$ 389.00 - Sold Out
Blackmagic Mini Converter SDI to Audio 4K
$ 389.00 - Sold Out
Blackmagic Mini Converter SDI to Audio 4K
Blackmagic SKU: BMD-CONVMCSAUD4K | Helix SKU: BMDCONVMCSAUD4K
Overview
Mini Converter SDI to Audio 4K includes everything you need to de‑embed 4 channels of analog audio or 8 channels of AES/EBU digital audio from any SDI video connection. Now you can access the audio in any SDI video connection for output to a massive range of audio equipment such as audio mixers, analog broadcast decks, audio monitors and more!
Specifications
Connections
SDI Video Inputs
1 x SD, HD or 6G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
SDI Video Outputs
1 x SDI Video Loop Output.
SDI Redundant Inputs
Automatically switches over if main SDI input is lost.
Analog Audio Outputs
4 channels of professional balanced analog audio with standard 1/4 inch jack connections.
Digital Audio Outputs
8 channels of professional balanced digital with standard 1/4 inch jack connections.
Multi Rate Support
Auto detection SD, HD or 6G‑SDI.
Updates and Configuration
USB
Reclocking
Yes
Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE424M-B, SMPTE 425M, SMPTE ST-2036, SMPTE ST‑2081, ITU‑R BT.656 and ITU‑R BT.601
SDI Video Rates
SDI video connections are switchable between standard definition and high definition.
SDI Video Sampling
4:2:2, 4:4:4
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2, 4:4:4
SDI Color Space
YUV, RGB
SDI Auto Switching
Automatically selects between SD, HD, 3G and 6G‑SDI.
Software
Software Control
Mac™ and Windows™ software upgrade via USB.
Internal Software Upgrade
Via included updater application.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Settings Control
Mini Switches or USB software.
Power Requirements
Power Supply
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Power Consumption
5.52 Watts
Operational Voltage Range
12V ‑ 31V DC
Physical Specifications
Environmental Specifications
Operating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
What's Included
Mini Converter SDI to Audio 4K
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Mini Converter SDI to HDMI 6G
$ 239.00 - Sold Out
Blackmagic Mini Converter SDI to HDMI 6G
$ 239.00 - Sold Out
Blackmagic Mini Converter SDI to HDMI 6G
Blackmagic SKU: BMD-CONVMBSH4K6G | Helix SKU: BMDCONVMBSH4K6G
Overview
Mini Converter SDI to HDMI 6G lets you convert from SDI to HDMI in SD, HD, and Ultra HD formats while de-embeding audio to HDMI, AES/EBU or balanced analog audio. You also get advanced features such as down conversion for monitoring Ultra HD on HD HDMI monitors as well as built in 3D LUTs plus HDMI instant lock for instant video display when an SDI input is connected!
Specifications
Connections
SDI Video Inputs
1 x SD, HD or 6G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
SDI Video Outputs
1 x SDI Video Loop Output.
HDMI Video Outputs
HDMI type A out.
Analog Audio Outputs
2 channels of balanced analog audio.
Digital Audio Outputs
4 channels of AES/EBU digital audio
SDI Redundant Input
Automatically switches over if main SDI input is lost.
Multi Rate Support
Auto detection of SD, HD or 6G‑SDI.
Updates and Configuration
USB
Reclocking
Yes
Standards
SD Video Standards
625i50 PAL, 525i59.94 NTSC
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M, SMPTE ST‑2081
SDI Video Rates
SDI video connections are switchable between standard definition, high definition, Level A or Level B 3G‑SDI and 6G‑SDI.
SDI Video Sampling
4:2:2 and 4:4:4
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2 and 4:4:4
SDI Color Space
YUV and RGB
SDI Auto Switching
Automatically detects SD, HD or 6G‑SDI.
HDMI Video Standards
625i50 PAL, 525i59.94 NTSC, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60, 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
HDMI Color Space
YUV and RGB
HDMI Color Precision
4:2:2 and 4:4:4
Software
Software Control
Mac OS and Windows software upgrade via USB.
Internal Software Upgrade
Via included updater application.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Settings Control
Mini Switches or USB software.
Power Requirements
+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Operational Voltage Range
12 ‑ 18V DC
Power Consumption
5.2 Watts
Physical Specifications
Environmental Specifications
Operating Temperature
0° to 40° C (32° to 104° F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
What's Included
Mini Converter SDI to HDMI 6G
12V universal power supply with international socket adapters
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic Pocket Cinema Camera 4K
$ 1,295.00 - Sold Out
Blackmagic Pocket Cinema Camera 4K
$ 1,295.00 - Sold Out
Blackmagic Pocket Cinema Camera 4K
Blackmagic SKU: BMD-CINECAMPOCHDMFT4K | Helix SKU: BMDCINECAMPOCHDMFT4K
Overview
The Blackmagic Pocket Cinema Camera 4K features a 4/3 size sensor, 13 stops of dynamic range and dual native ISO up to 25,600 for HDR images and incredible low light performance. External controls give quick access to essential functions, while the large 5 inch touchscreen makes it easy to frame shots, focus accurately and change camera settings. Features include built in SD/UHS-II or CFast 2.0 recorders for Blackmagic RAW or ProRes recoding as well as a USB-C expansion port for recording externally to disks, plus MFT lens mount, built-in microphones, XLR input, full sized HDMI, 3D LUT support, Bluetooth and more.
Specifications
Camera Features
Effective Sensor Size
18.96mm x 10mm (Four Thirds)
Lens Mount
Active MFT mount.
Lens Control
Iris, focus and zoom on supported lenses.
Dynamic Range
13 Stops.
Dual Native ISO
400 and 3200
Shooting Resolutions
4096 x 2160 (4K DCI), 3840 x 2160 (Ultra HD), 1920 x 1080 (HD).
Frame Rates
Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported.
Off-speed frame rates up to 60 fps in 4K DCI, 120 fps in HD windowed.
Focus
Auto focus available using compatible lenses.
Iris Control
Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses.
Screen Dimensions
5” 1920 x 1080.
Screen Type
LCD capacitive touchscreen.
Metadata Support
Automatically populated lens data from electronic Micro Four Thirds lenses. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.
Controls
Touchscreen menus on 5 inch screen. 1 x Power Switch, 1 x Record Button, 1 x Stills Button, 1 x Scroll Wheel with push integrated into handgrip, 1 x ISO Button, 1 x White Balance, 1 x Shutter Button, 3 x software configurable Fn buttons, 1 x High Frame Rate (HFR) Button, 1 x Zoom Button, 1 x Menu Button, 1 x Play Button, 1 x Focus Button and 1 x IRIS Button.
Connections
Total Video Inputs
None.
Total Video Outputs
1 x HDMI Type A
Analog Audio Inputs
1 x mini XLR analog switchable between mic with phantom power support and line level (up to +14dBu). 1 x 3.5mm Stereo Input. Can also be used for Timecode input.
Analog Audio Outputs
1 x 3.5mm headphone jack.
Computer Interface
USB Type-C for external drive recording and software updates.
Audio
Microphone
Integrated stereo microphone.
Built in Speaker
1 x mono speaker.
Standards
SD Video Standards
None.
HD Video Standards
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60.
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60.
4K DCI Standards
4KDCIp23.98, 4KDCIp24, 4KDCIp25, 4KDCIp29.97, 4KDCIp30, 4KDCIp50, 4KDCIp59.94, 4KDCIp60.
Media
Media
1 x CFast card slot, 1 x SD UHS-II card slot, 1 x USB-C 3.1 Gen 1 expansion port for external media for Blackmagic RAW and ProRes Recording.
Media Format
Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems.
Supported Codecs
Codecs
Blackmagic RAW Constant Bitrate 3:1,
Blackmagic RAW Constant Bitrate 5:1,
Blackmagic RAW Constant Bitrate 8:1,
Blackmagic RAW Constant Bitrate 12:1,
Blackmagic RAW Constant Quality Q0,
Blackmagic RAW Constant Quality Q5,
ProRes 422 HQ QuickTime,
ProRes 422 QuickTime,
ProRes 422 LT QuickTime,
ProRes 422 Proxy QuickTime.
Storage Features
Storage Type
1 x CFast 2.0.
1 x SD UHS-II card.
1 x high speed USB-C expansion port for external media.
Storage Rates
Storage rates based on 30 frames per second.
4096 x 2160
Blackmagic RAW 3:1 - 135 MB/s
Blackmagic RAW 5:1 - 81 MB/s
Blackmagic RAW 8:1 - 51 MB/s
Blackmagic RAW 12:1 - 34 MB/s
Blackmagic RAW Q0 - 81 to 203 MB/s *
Blackmagic RAW Q5 - 21 to 58 MB/s **
Apple ProRes 422 HQ - 117.88 MB/s
Apple ProRes 422 - 78.63 MB/s
Apple ProRes 422 LT - 54.63 MB/s
Apple ProRes Proxy - 24.25 MB/s
3840 x 2160
Blackmagic RAW 3:1 - 127 MB/s
Blackmagic RAW 5:1 - 76 MB/s
Blackmagic RAW 8:1 - 48 MB/s
Blackmagic RAW 12:1 - 32 MB/s
Blackmagic RAW Q0 - 76 to 190 MB/s *
Blackmagic RAW Q5 - 19 to 55 MB/s **
Apple ProRes 422 HQ - 110 MB/s
Apple ProRes 422 - 73.6 MB/s
Apple ProRes 422 LT - 51 MB/s
Apple ProRes Proxy - 22.4 MB/s
1920 x 1080
Blackmagic RAW 3:1 - 33 MB/s
Blackmagic RAW 5:1 - 20 MB/s
Blackmagic RAW 8:1 - 13 MB/s
Blackmagic RAW 12:1 - 8 MB/s
Blackmagic RAW Q0 - 20 to 49 MB/s *
Blackmagic RAW Q5 - 5 to 14 MB/s **
Apple ProRes 422 HQ - 27.5 MB/s
Apple ProRes 422 - 18.4 MB/s
Apple ProRes 422 LT - 12.75 MB/s
Apple ProRes Proxy - 5.6 MB/s
Recording Formats
Blackmagic RAW Q0, Q5, 3:1, 5:1, 8:1 and 12:1 at 4096 x 2160, 3R0 and 1920 x 1080 with film, extended video or video dynamic range. ProRes at 4096 x 2160, 3840 x 2160 and 1920 x 1080 with film, extended video or video dynamic range or custom 3D LUT.
*
Constant Quality setting Q0 storage rates quoted are indicative only, based on a 2:1 - 5:1 compression range.
**
Constant Quality setting Q5 storage rates quoted are indicative only, based on a 7:1 - 20:1 compression range.
Actual storage rates are entirely dependent on image subject matter.
Software
Software Included
Pocket Cinema Camera 4K Operating System.
DaVinci Resolve Studio on SD Card.
Blackmagic Camera Setup.
Operating Systems
Mac 10.13 High Sierra,
Mac 10.14 Mojave or later.
Windows 8.1 or Windows 10.
Power Requirements
Power Supply
1 x External 12V power supply.
External Power Input
1 x 2-pin locking connector.
Battery Type
Canon LP-E6.
Battery Life
Approximately 60 minutes
(recording at 24 fps without any external USB-C device connected)
Power
12V-20V
Physical Specifications
Environmental Specifications
Operating Temperature
0°to 40°C (32° to 104°F)
Storage Temperature
-20°to 45°C (-4° to 113°F)
Relative Humidity
0
What's Included
Blackmagic Pocket Cinema Camera 4K
Lens turret dust cap.
30W power supply with locking connector and international adapters.
LP‑E6 Battery
SD card with software and manual.
Welcome card.
DaVinci Resolve Studio with activation key.
Warranty
Product Warranty
12 Month Limited Manufacturer's Warranty.
Blackmagic Studio Camera 4K 2
$ 1,695.00 - Sold Out
Blackmagic Studio Camera 4K 2
$ 1,695.00 - Sold Out
Blackmagic Studio Camera 4K 2
Blackmagic SKU: BMD-CINSTUDMFT/UHD/2 | Helix SKU: BMDCINSTUDMFTUHD2
Overview
The Blackmagic Studio Camera 4K is the live broadcast camerathat’s ready for multi camera Ultra HD production today. Featuring a massive 10 inch viewfinder, MFT lens mount, talkback, tally indicators, phantom powered microphone connections, 12G-SDIand user upgradeable optical fiber connections that let you connect to your switcher with a single cable! The advanced 4K model is switchable to 1080 HD, that means you can work in HD today and you’re always ready for Ultra HD production.
Specifications
Camera Features
Effective Sensor Size
13.056mm x 7.344mm
Focus
Auto focus. Peaking mode
Lens Mount
Active MFT Mount
Lens Control
Iris, focus, zoom on supported lenses
Dynamic Range
11 Stops
Screen Dimensions
1 x 10.1 inch 1920 x 1200
Screen Type
10.1 inch - TFT-LCD
Mounting Options
2 x 3/8” tripod mount. 4 x 1/4""-20 UNC thread mounting points on top of camera. 3 x 1/4” 20 UNC thread mounting points left on right of camera
Connections
Total Video Inputs
1 x SDI
Total Video Outputs
1 x SDI
SDI Rates
1.5G, 3G, 6G, 12G
Optical SDI
Supports optional SMPTE optical module
Optical Fiber Input/Outputs
12G Optical Fiber Input and Output capable
Optical fiber SFP module sold separately
Analog Audio Inputs
2 x XLR , phantom power
Analog Audio Outputs
Aviation headphone jacks (Fixed Wing Plugs) output for talkback and audio monitoring
Reference Input
Tri-Sync or Black Burst.
SDI Audio Outputs
2 channels in 12G-SDI 48Khz and 24 bit. 2 channels for talkback on channel 15 - 16
Remote Control
1 x 2.5mm LANC for Iris Control and Focus. SDI CCU control from ATEM
Computer Interface
USB 2.0 Mini-B port for software updates
Audio
Microphone
Integrated stereo microphone
Built in Speaker
None
Standards
SD Video Standards
None
HD Video Standards
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94 and 1080i60
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94 and 2160p60
SDI Compliance
SMPTE 292M, SMPTE 424M Level B, SMPTE 2081-1, SMPTE 2082-1
SDI Audio Sampling
48 kHz and 24-bit
Media
Media
None
Media Format
None
Supported Codecs
Codecs
None
Control
Controls
Push button controls for navigating menus
External Control
Blackmagic SDI Control Protocol. 2.5 mm LANC connection for lens control
Color Corrector
DaVinci YRGB
Talkback and Tally
Live Tally Indicator
1 x for talent, 1 x for operator
Talkback
SDI Channels 15 and 16
Software
Software Included
Blackmagic Camera Setup for Mac and Windows
Operating Systems
Mac 10.11 El Capitan,
Mac 10.12 Sierra or later.
Windows 8.1 or Windows 10.
Power Requirements
1 x External 12V power supply
Optional Accessories
SMPTE compatible SFP Optical Module
Blackmagic Studio Camera 4K
Physical Specifications
Environmental Specifications
Operating Temperature
0° to 40° C (32° to 104° F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
What's Included
Blackmagic Studio Camera 4K
Sun Shield and attachment screws
Turret Dust Cap
12V AC Adapter
SD card with software and manual
Warranty
12 Month Limited Manufacturer's Warranty
Blackmagic Studio Fiber Converter
$ 3,959.00 - Sold Out
Blackmagic Studio Fiber Converter
$ 3,959.00 - Sold Out
Blackmagic Studio Fiber Converter
Blackmagic SKU: BMD-CINEURSANWFRSTUD | Helix SKU: BMDCINEURSANWFRSTUD
Overview
Work with remote cameras up to 2 km away from your studio or outside broadcast truck using SMPTE fiber. The Blackmagic Studio Fiber Converter converts SDI video, audio, and remote camera control connections into a single optical fiber cable, which connects to a Blackmagic Camera Fiber Converter attached to a remote camera. All video and data are transmitted using standard IP for extremely low latency broadcast quality video. You get 12G-SDI for an HD or Ultra HD camera feed and 3 independent HD return feeds, along with standard connections for camera control, PTZ, two dual channel talkback intercoms, tracker talkback, tally and a 5 inch LCD screen for monitoring camera and return feeds. The Blackmagic Studio Fiber Converter also provides power for your remote cameras and accessories.
Specifications
Connections
Optical Fiber Input
1x SMPTE Hybrid Fiber Optic
with Female SMPTE 304 connector.
SDI Video Input
3x 12G SDI Return feeds with Program,
Camera Control, Tally, Genlock and Intercom on Return 1.
SDI Video Output
2x 12G SDI for Ultra HD up to 60p.
Talkback Audio
SDI Channels 15 and 16 for Production,
Analogue in and out supported via 25-pin connector for Production and Engineering talkback support.
Balanced XLR Audio Outputs
4x camera analogue audio outputs.
Optical Fiber Outputs
1x Optical I/O via 10 Gb-E
(not currently active).
Computer Interface
1x USB-C.
Standards
HD Video Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25,
2160p29.97, 2160p30, 2160p60
SDI Compliance
SMPTE 259M, SMPTE 292M, 296M,
372M, 424M Level B, 425M.
Audio Sampling
Television standard sample
rate of 48Khz, 24 bit A/D conversion.
Video Sampling
4:2:2
Color Precision
10-bit
Color Space
REC 709, REC 2020.
Multiple Rate Support
SDI switches between HD,
3G-SDI, 6G-SDI and 12G-SDI.
Software
Software Included
Camera Utility for firmware update.
Operating Systems
Mac 10.11 El Capitan,
Mac 10.12 Sierra or later.
Windows 8.1 or Windows 10.
Power Requirements
Power Supply
110 - 240V AC input.
Physical Specifications
Environmental Specifications
Operating Temperature
0° to 50° C (32° to 122° F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
What's Included
Blackmagic Studio Fiber Converter
SD card with software and manual
Warranty
1 Year Limited Manufacturer's Warranty.
Blackmagic UltraStudio 4K Extreme 3
$ 3,839.00 - Sold Out
Blackmagic UltraStudio 4K Extreme 3
$ 3,839.00 - Sold Out
Blackmagic UltraStudio 4K Extreme 3
Blackmagic SKU: BMD-BDLKULSR4KEXTR/3 | Helix SKU: BMDBDLKULSR4KEXTR3
Overview
UltraStudio 4K Extreme 3 is the world’s most advanced capture and playback solution for PCI Express and Thunderbolt computers! It features incredibly fast 40Gb/s Thunderbolt 3, advanced 12G‑SDI and HDMI 2.0 connections for working at up to 60 frames per second with deep color, 12‑bit RGB, support for HDR workflows via HDMI 2.0a and extremely large 4K frame sizes. Featuring the widest range of analog and digital connections, UltraStudio 4K Extreme 3 is compatible with virtually any camera, deck, router or display. There’s even an extremely powerful hardware encoder built-in that supports realtime H.265 encoding!
Specifications
Connections
SDI Video Inputs
2 x 12Gb/s and 2 x 6Gb/s SD/HD/2K/4K. Supports single/dual/quad link 4:2:2/4:4:4. 2D/3D switchable.
SDI Video Outputs
2 x 12Gb/s and 2 x 6Gb/s SD/HD/2K/4K. Supports single/dual/quad link 4:2:2/4:4:4. 2D/3D switchable.
SDI Rates
270Mb, 1.5G, 3G, 6G, 12G.
Optical SDI
Supports 2 optional SMPTE modules.
SDI Video Loop
4 x reclocked SD/HD/2K/4K linked to corresponding inputs.
SDI Video Repeated Outputs
2 x 12Gb/s and 2 x 6Gb/s SD/HD/2K/4K. Supports single/dual/quad link 4:2:2/4:4:4. 2D/3D switchable.
Analog Video Inputs
1 x Component YUV on 3 BNCs, 1 x composite NTSC/PAL on 1 BNC.
Analog Video Outputs
1 x Component YUV on 3 BNCs, 1 x composite NTSC/PAL on 1 BNC.
Analog Audio Inputs
4 Channels of professional balanced analog audio via XLR connectors and 2 channels of consumer unbalanced via RCA connectors.
Analog Audio Outputs
4 Channels of professional balanced analog audio via XLR connectors.
Optical Fiber Inputs/Outputs (Optional)
2 x 12Gb/s Optical Fiber.
AES/EBU Audio Inputs
2 Channels unbalanced with sample rate converter on BNC connector.
AES/EBU Audio Outputs
2 Channels unbalanced on BNC connector.
SDI Audio Inputs
16 Channels embedded in SD/HD/2K/4K.
SDI Audio Outputs
16 Channels embedded in SD/HD/2K/4K.
HDMI Video Inputs
HDMI 2.0 type A connector with support for 2160p60
HDMI Video Outputs
HDMI 2.0 type A connector with support for 2160p60
HDMI Audio Inputs
8 Channels embedded in SD/HD/4K.
HDMI Audio Outputs
8 Channels embedded in SD/HD/4K.
Mic Input
1 x 48V microphone input via XLR connector. Phantom Power switchable via software control.
Timecode Input
1 x XLR Input.
Timecode Output
1 x XLR Output.
Sync Input
1 x Reference input. Tri-Sync or Black Burst.
Sync Output
1 x Reference Loop Output. Tri-Sync or Black Burst.
Computer Interface
Thunderbolt™ 3 (Mac OS and Windows), PCI Express 4 lane generation 2.
Power
2 x built-in international AC power supply with IEC C14 inlet. 120-240V, 50-60Hz.
Supported Codecs
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8‑bit 4:2:2, Uncompressed 10‑bit 4:2:2, Uncompressed 10‑bit 4:4:4.
Software
Software Included
DaVinci Resolve, Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.
Internal Software Upgrade
Firmware built into software driver. Software driver loads upgrades at system start or via updater software.
Software Applications
DaVinci Resolve
Fusion
Final Cut Pro X
Adobe Premiere Pro CC
Avid Media Composer
Adobe After Effects CC
Avid Pro Tools
Steinberg Cubase
Steinberg Nuendo
Adobe Photoshop CC
Other supported applications include:
The Foundry Nuke, Grass Valley Edius, Sony Catalyst Production Suite, Tools On Air Just: Play & Live & In, Softron MovieRecorder & MReplay, Adobe Flash Media Live Encoder, Telestream Wirecast, Livestream Producer, Resolume Arena, Magix Vegas Pro & Movie Edit Pro Premium, Corel VideoStudio Pro, CyberLink PowerDirector, Vidblaster X & Studio & Broadcast, Uniplay One & CG, CasparCG Server, Magicsoft CG, Xsplit Broadcaster, Imagine Communications Velocity & InfoCaster, DevTek Easy Media Suite, Metus Ingest, Boinx Software MimoLive, Cinegy Capture Pro, vMix Live, Renewed Vision ProPresenter, Ventuz Director, Class X Liveboard & Coral CG, Glookast Capturer, Open Broadcaster Software Studio, Nautilus NEMO3D.
SDI Video Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
1080i50, 1080i59.94, 1080i60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p
2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
3D Video Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30,
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
1080i50, 1080i59.94, 1080i60
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p
2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, SMPTE 435, SMPTE 2081, SMPTE 2082, ITU-R BT.656 and ITU-R BT.601.
SDI Metadata Support
RP 188/SMPTE 12M-2 and closed captioning.
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24‑bit.
SDI Video Sampling
4:2:2, 4:4:4
SDI Color Space
REC 601, REC 709.
SDI Configuration
SDI output is configurable for Quad Link 3Gb/s via Blackmagic Desktop Video Utility. When using single link 12Gb/s on SDI A or dual link 6Gb/s on SDI A and B, SDI C and D will output downconverted HD.
HDMI Video Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
3D Video Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30,
1080i50, 1080i59.94, 1080i60
HDMI Audio Sampling
Television standard sample rate of 48 kHz and 24‑bit.
HDMI Video Sampling
4:4:4, 4:2:2 & 4:2:0
HDMI Configuration
HDMI 2.0a supports Deep Color and HDR. Automatically configures to connected display.
Multiple Rate Support
HDMI and SDI video connections are switchable between SD/HD/2K and 4K. Component analog video connections are switchable between SD and HD.
Copy Protection
HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
Hardware Frame Buffer
v210 (10 bit YUV), 2vuy (8 bit YUV), ARGB, BGRA (8 bit RGB), r210 (10 bit RGB), R12B,R12L (12 bit RGB).
Color Precision
8, 10, 12‑bit RGB 4:4:4 up to 2160p30 and 8, 10‑bit YUV 4:2:2 in all standards.
Computer Capture
2 x Thunderbolt 3 for Mac and Windows plus PCI Express Gen 2 for Mac, Windows and Linux. Includes Blackmagic Desktop Video SDK.
Control
Built in Control Panel
14 buttons for input selection. 5 inch color display.
Device Control
2 x RS-422 deck control.
Processing
Encoding
Hardware based real time h.265 encoder.
Ultra HD Down Conversion
Built in, high quality hardware down converter outputs Ultra HD to HD with down-converted signal on SDI outputs C & D and HDMI output when connected to an HD‑only TV.
HD to SD Down Conversion
Built in, high quality hardware down converter outputs HD to SD with down-converted signal on SDI output B, Component and Composite NTSC/PAL. SD output selectable between letterbox, anamorphic 16:9 and center cut 4:3.
HD Up Conversion
Built in, high quality hardware up conversion from SD to 720HD or 1080HD on playback. Selectable between 4:3 pillarbox, 14:9 zoom and 16:9 zoom.
HD Cross Conversion
Built in, high quality hardware cross conversion from 720p to 1080HD and 1080HD to 720p on playback.
Real Time Effects
DaVinci Resolve, Final Cut Pro X internal effects. Adobe Premiere Pro CC Mercury Playback Engine effects. Avid Media Composer internal effects.
Colorspace Conversion
Hardware based real time.
3D Processing
Dual stream and frame packed capture & playback.
Physical Installation
Requires a computer with either a Thunderbolt port or available PCI Express slot. Blackmagic PCI Express Cable Kit available separately for high speed PCI Express Gen 3 connection. Please check support pages to see the full system requirement.
Operating Systems
Mac 10.13 High Sierra,
Mac 10.14 Mojave or later.
Windows 7, 8.1 and 10, all 64-bit.
Linux
Power Requirements
2 x Internal 120 - 240V AC
EMC Certifications
FCC, CE and C-Tick.
Physical Specifications
Environmental Specifications
Operating Temperature
5° to 40° C (41° to 104° F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
What's Included
UltraStudio 4K Extreme 3
SD card with software and manual
DaVinci Resolve SD card
Warranty
3 Year Limited Manufacturer's Warranty.
Blackmagic UltraStudio HD Mini
$ 649.00 - Sold Out
Blackmagic UltraStudio HD Mini
$ 649.00 - Sold Out
Blackmagic UltraStudio HD Mini
Blackmagic SKU: BMD-BDLKULSDMINHD | Helix SKU: BMDBDLKULSDMINHD
Overview
UltraStudio HD Mini features professional broadcast quality connections that include 3G-SDI, analog YUV and composite NTSC/PAL video inputs, along with a reference input. There are also two ¼” audio connections for analog audio input that work with balanced and HiFi sources. In addition, UltraStudio HD Mini can remote control professional broadcast decks using the built in RS-422 connection. For output, you get dual link 3G-SDI with fill and key, and an HDMI connection for monitoring video with a big screen television!
Specifications
Connections
SDI Video Inputs
1 x 3Gb/s SD/HD switchable.
SDI Video Outputs
2 x 3Gb/s SD/HD switchable, supports fill and key.
SDI Rates
270Mb, 1.5G, 3G
Optical SDI
None
HDMI Video Inputs
None
HDMI Video Outputs
1 x HDMI 1.4b type A connector.
Analog Video Inputs
Y, B-Y, R-Y/NTSC/PAL.
Analog Video Outputs
None
Analog Audio Inputs
2 x 1/4 inch jack connectors for balanced and unbalanced analog audio.
Analog Audio Outputs
None, embedded audio only.
SDI Audio Inputs
16 Channels embedded in SD and HD.
SDI Audio Outputs
16 Channels embedded in SD and HD.
HDMI Audio Outputs
2 Channels embedded in SD and HD.
Timecode Connection
None. RP-188 only.
Reference Input
Tri-Sync or Black Burst.
Supported Codecs
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHD, DNxHR, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10‑bit 4:2:2.
Software
Software Included
Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.
Internal Software Upgrade
Firmware built into software driver. Software driver loads upgrades at system start or via updater software.
Software Applications
DaVinci Resolve
Fusion
Final Cut Pro X
Adobe Premiere Pro CC
Avid Media Composer
Adobe After Effects CC
Avid Pro Tools
Steinberg Cubase
Steinberg Nuendo
Adobe Photoshop CC
Other supported applications include:
The Foundry Nuke, Grass Valley Edius, Sony Catalyst Production Suite, Tools On Air Just: Play & Live & In, Softron MovieRecorder & MReplay, Adobe Flash Media Live Encoder, Telestream Wirecast, Livestream Producer, Resolume Arena, Magix Vegas Pro & Movie Edit Pro Premium, Corel VideoStudio Pro, CyberLink PowerDirector, Vidblaster X & Studio & Broadcast, Uniplay One & CG, CasparCG Server, Magicsoft CG, Xsplit Broadcaster, Imagine Communications Velocity & InfoCaster, DevTek Easy Media Suite, Metus Ingest, Boinx Software MimoLive, Cinegy Capture Pro, vMix Live, Renewed Vision ProPresenter, Ventuz Director, Class X Liveboard & Coral CG, Glookast Capturer, Open Broadcaster Software Studio, Nautilus NEMO3D.
Video Standards
SD Video Standards
525i59.94 NTSC, 625i50 PAL
HD Video Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
1080i50, 1080i59.94, 1080i60
2K Video Standards
2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
Ultra HD Video Standards
None
4K Video Standards
None
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M and SMPTE 425M A/B.
SDI Metadata Support
RP 188/SMPTE 12M-2 and closed captioning.
Audio Sampling
Television rate of 48kHz and 24 bit.
SDI Video Sampling
4:2:2/4:4:4
Color Space
REC 601, REC 709.
HDMI Resolution
Pixel for pixel HD resolution input from connected device.
Multiple Rate support
SDI and HDMI video connections are switchable between standard definition and high definition. SDI switches between 270 Mb/s, 1.5 Gb/s and 3 Gb/s.
Hardware Frame Buffer
v210 (10 bit YUV), 2vuy (8 bit YUV), ARGB, BGRA (8 bit RGB), r210 (10 bit RGB), R12B,R12L (12 bit RGB).
Color Precision
8, 10, 12-bit RGB 4:4:4 up to 1080p30, and 8, 10-bit YUV 4:2:2 in all standards.
Computer Capture
1 x Thunderbolt™ 3 for Mac and Windows. Powers from Thunderbolt host computer, includes Blackmagic Desktop Video SDK.
Control
Built in Control Panel
None. Supports Teranex Mini Smart Panel with 2.2 inch color display for video preview, audio meters and status.
Device Control
1 x RS-422 deck control.
Processing
Colorspace Conversion
Hardware based real time.
HD Down Conversion
Real time 10-bit hardware down conversion on SDI B output when working in HD video formats on playback. Selectable between letterbox, anamorphic 16:9 and center cut 4:3 styles.
Real Time Effects
Final Cut Pro X internal effects. Premiere Pro CC Mercury Playback Engine effects. Avid Media Composer internal effects. DaVinci Resolve.
Physical Installation
Requires computer with a Thunderbolt™ 3 USB-C port. Please check support pages to see the full system requirements.
Operating Systems
Mac 10.13 High Sierra,
Mac 10.14 Mojave or later.
Windows 7, 8.1 and 10, all 64-bit.
Linux
Power Requirements
Powered by Thunderbolt cable. Requires computer with a Thunderbolt™ 3 USB-C port.
Physical Specifications
Environmental Specifications
Operating Temperature
5° to 40° C (32° to 104° F)
Storage Temperature
-20° to 45° C (-4° to 113° F)
What's Included
UltraStudio HD Mini
SD card with software and manual
DaVinci Resolve SD card
Warranty
3 Year Limited Manufacturer's Warranty.
Relative Humidity
0% to 90% non-condensing
Blackmagic URSA Gold Battery Plate
$ 155.00 - Sold Out
Blackmagic URSA Gold Battery Plate
$ 155.00 - Sold Out
Blackmagic URSA Gold Battery Plate
Blackmagic SKU: BMD-CINEURVBATTGOLD | Helixc SKU: BMDCINEURVBATTGOLD
Overview
Gold mount compatible battery plate with Molex connector for attaching third party batteries to URSA cameras.
Blackmagic URSA Mini Mic Mount
$ 189.00 - Sold Out
Blackmagic URSA Mini Mic Mount
$ 189.00 - Sold Out
Blackmagic URSA Mini Mic Mount
Blackmagic SKU: BMD-CINEURSASHSMC | Helix SKU: BMDCINEURSASHSMC
Overview
Add a shock and vibration isolated professional microphone mount to your URSA Mini or URSA Mini Pro camera!
Blackmagic URSA Mini Pro B4 Mount
$ 559.00 - Sold Out
Blackmagic URSA Mini Pro B4 Mount
$ 559.00 - Sold Out
Blackmagic URSA Mini Pro B4 Mount
Blackmagic SKU: BMD-CINEURSAMUPROTB4HD | Helix SKU: BMDCINEURSAMUPROTB4HD
Overview
Turn your URSA Mini Pro into an incredibly compact broadcast camera that you can use with your existing high definition B4 broadcast lenses! URSA Mini Pro features a standard 12-pin Hirose lens control connection that’s compatible with both B4 and PL lenses. You can remotely control record start/stop, iris and motorized zoom lenses!
Specifications
Lens Mount Features
Optics Resolution
2048 x 1152
Image Circle
10.56mm x 5.94mm
Magnification
1.1x
Lens Mount
B4 Bayonet style with locking ring
B4 Spherical Aberration Correction
Yes
Physical Specifications
What's Included
Blackmagic URSA Mini Pro B4 Mount
Moulded Mount Case
Turret Dust Cap
Lens Rear Protective Cover
Shim Set
Spare Mounting Screws
Printed Instructions
Warranty
12 Month Limited Manufacturer's Warranty.
Blackmagic URSA Mini Pro EF Mount
$ 195.00 - Sold Out
Blackmagic URSA Mini Pro EF Mount
$ 195.00 - Sold Out
Blackmagic URSA Mini Pro EF Mount
Blackmagic SKU: BMD-CINEURSAMUPROTEF | Helix SKU: BMDCINEURSAMUPROTEF
Overview
The Blackmagic URSA Mini Pro EF Mount lets you use high quality Canon compatible photo lenses with your URSA Mini Pro camera.
What's Included
Blackmagic URSA Mini Pro EF Mount
Moulded Mount Case
Shim Set
Baffle Tool
Spare Mounting Screws
Printed Instructions
Warranty
12 Month Limited Manufacturer's Warranty.
Blackmagic URSA Mini Pro F Mount
$ 545.00 - Sold Out
Blackmagic URSA Mini Pro F Mount
$ 545.00 - Sold Out
Blackmagic URSA Mini Pro F Mount
Blackmagic SKU: BMD-CINEURSAMUPROTF | Helix SKU: BMDCINEURSAMUPROTF
Overview
The URSA Mini Pro F Mount lets you use your favorite Nikon stills lenses with smooth high precision mechanical iris control. Now you can pair digital film quality with classic Nikon AF-S G and AF-D series lenses.
What's Included
Blackmagic URSA Mini Pro F Mount
F Mount Turret Dust Cap
Moulded Mount Case
Shim Set
Spare Mounting Screws
Printed Instructions
Warranty
12 Month Limited Manufacturer's Warranty.
Blackmagic URSA Mini Pro PL Mount
$ 275.00 - Sold Out
Blackmagic URSA Mini Pro PL Mount
$ 275.00 - Sold Out
Blackmagic URSA Mini Pro PL Mount
Blackmagic SKU: BMD-CINEURSAMUPROTPL | Helix SKU: BMDCINEURSAMUPROTPL
Overview
The Blackmagic URSA Mini Pro PL Mount lets you use the world’s highest quality professional cinema lenses with your URSA Min Pro camera. The PL lens mount features contact pins for compatibility with Cooke’s i/Technology protocol so information such as lens make and model, serial number, iris setting, focus distance and zoom position can be saved as metadata and used in software like DaVinci Resolve. In addition, you can also power and control broadcast style cine-servo zoom lenses using the camera’s 12-pin Hirose connector.
What's Included
Blackmagic URSA Mini Pro PL Mount
Moulded Mount Case
Shim Set
PL Baffle
Baffle Tool
Spare Mounting Screws
Printed Instructions
Warranty
12 Month Limited Manufacturer's Warranty.
Blackmagic URSA Mini Pro Shim Kit
$ 89.00 - Sold Out
Blackmagic URSA Mini Pro Shim Kit
$ 89.00 - Sold Out
Blackmagic URSA Mini Pro Shim Kit
Blackmagic SKU: BMD-CINEURSAMUPROSHM | Helix SKU: BMDCINEURSAMUPROSHM
Overview
Set of 9 shims and baffle tool for making precise changes to the flange focal distance for URSA Mini Pro's EF, PL or B4 mount.
Blackmagic URSA Mini Shoulder Kit
$ 435.00 - Sold Out
Blackmagic URSA Mini Shoulder Kit
$ 435.00 - Sold Out
Blackmagic URSA Mini Shoulder Kit
Blackmagic SKU: BMD-CINEURSASHMKM | Helix SKU: BMDCINEURSASHMKM
Overview
Be ready to shoot anywhere! Kit includes shoulder pad with built in rosettes, rail mounts, integrated tripod quick lock release and top handle.
Blackmagic URSA PL Shim Set
$ 85.00 - Sold Out
Blackmagic URSA PL Shim Set
$ 85.00 - Sold Out
Blackmagic URSA PL Shim Set
Blackmagic SKU: BMD-CINEURVPLSHIM | Helix SKU: BMDCINEURVPLSHIM
Overview
Set of 8 shims for changing the flange focal distance for PL lenses with URSA PL and URSA Mini PL.
Blackmagic URSA Viewfinder
$ 1,679.00 - Sold Out
Blackmagic URSA Viewfinder
$ 1,679.00 - Sold Out
Blackmagic URSA Viewfinder
Blackmagic SKU: BMD-CINEURSANEVFP | Helix SKU: BMDCINEURSANEVFP
Overview
The Blackmagic URSA Viewfinder is the perfect accessory to make outdoors and handheld shooting with your URSA or URSA Mini digital film camera easy. You get an extremely high quality viewfinder with 1080HD resolution display, true precision glass optics, built in tally light and built in menus, overlays and even a digtal focus chart!
Specifications
Connections
SDI Video Inputs
1 x 3G-SDI BNC.
Power Input
1 x 4 pin XLR 12V.
Computer Interface
USB 2.0 Mini-B port for software updates.
Features
Display Resolution
Full 1920 x 1080.
Frame Rate
Up to 60fps
Display Type
OLED
Display Pixels
6.22 Million Pixels
Color Precision
24 bit RGB, 16.7 million colors
Focus
4 Element diopter.
Diopter Range
-4 to +3
Controls
Buttons for settings, short cut features and navigating menus.
Overlays
Built in overlay display processor and top mounted buttons.
Eyepiece
Can be tilted vertically and extended for left or right eye use.
Tally
LED tally light.
Mounting Options
Camera mount with adjustment.
Metadata Support
Detects camera information embedded in the SDI signal from URSA, URSA Mini and Blackmagic 3G-SDI Shield for Arduino.
Operating Systems
Mac 10.12 Sierra,
Mac 10.13 High Sierra or later.
Windows 8.1 or Windows 10.
Power Requirements
12V power input via 4 pin XLR connected via 12v power output.
Physical Specifications
Environmental Specifications
Operating Temperature
0° to 40° C (32° to 104° F)
Storage Temperature
-20° to 60° C (-4° to 140° F)
Relative Humidity
0% to 90% non-condensing
What's Included
Blackmagic URSA Viewfinder
3/8 inch viewfinder mounting thumb screw for URSA
Warranty
12 Month Limited Manufacturer’s Warranty.
Blackmagic URSA VLock Battery Plate
$ 155.00 - Sold Out
Blackmagic URSA VLock Battery Plate
$ 155.00 - Sold Out
Blackmagic URSA VLock Battery Plate
Blackmagic SKU: BMD-CINEURVLBATTAD | Helix SKU: BMDCINEURVLBATTAD
Overview
VLock compatible battery plate for attaching third party batteries to URSA cameras.
Blow Off Air Duster - 10oz
$ 9.95
Blow Off Air Duster - 10oz
$ 9.95
Blow Off Air Duster - 10oz
Helix SKU: PR4445
Overview
Blow Off Air Duster is an ozone safe, all purpose, sterilized, cleaner that removes dust, dirt and microscopic debris from difficult to reach places.
Recommended For: Computers, Keyboards, Photo Equipment*, Cash Registers, Printers, Fax Machines, Copiers, Telephones, Lab Equipment, TVs, VCRs, Typewriters, Vacuums, Shredders, Scanners, Stereos, Watches, Clocks, Mailing Machines, Fans, Audio Equipment, Electric Razors, Sports Equipment, Musical Instruments, Fire Arms, and more...
*Not recommended for digital imaging sensor cleaning.
Blow Off Air Duster - 3.5oz
$ 6.95
Blow Off Air Duster - 3.5oz
$ 6.95
Blow Off Air Duster - 3.5oz
Helix SKU: PR4431
Overview
Blow Off Air Duster is an ozone safe, all purpose, sterilized, cleaner that removes dust, dirt and microscopic debris from difficult to reach places.
Recommended For: Computers, Keyboards, Photo Equipment*, Cash Registers, Printers, Fax Machines, Copiers, Telephones, Lab Equipment, TVs, VCRs, Typewriters, Vacuums, Shredders, Scanners, Stereos, Watches, Clocks, Mailing Machines, Fans, Audio Equipment, Electric Razors, Sports Equipment, Musical Instruments, Fire Arms, and more...
*Not recommended for digital imaging sensor cleaning.
Bogen 12 inch Ceiling Bracket #0944
$ 40.00
Bogen 12 inch Ceiling Bracket #0944
$ 40.00
Bogen 12 inch Ceiling Bracket #0944
Bogen 3430 14-Inch Leg Protectors for 3011 and 3021 Series Tripods (Set of 3)
$ 27.95 - Sold Out
Bogen 3430 14-Inch Leg Protectors for 3011 and 3021 Series Tripods (Set of 3)
$ 27.95 - Sold Out
Set of 3 Manfrotto Patented Leg Warmers, which have a zip system so they can be easily fi tted and will not slip down in use. Offer good grip. Protect the legs and insulate your hands when using the tripod in cold weather.
Bogen Adjustable Ceiling Bracket #0943
$ 19.00
Bogen Adjustable Ceiling Bracket #0943
$ 19.00
Bogen Adjustable Ceiling Bracket #0943
Bogen SKU: 0943 | Helix SKU BO0943
Bogen Imaging Manfrotto 529B Hi Hat
$ 308.99 - Sold Out
Bogen Imaging Manfrotto 529B Hi Hat
$ 308.99 - Sold Out
Manfrotto's Hi-Hat enables you to get shots from the dog's perspective. The 529B has adjustable leg angles to mount the camera in the tightest or lowest of locations - and thanks to the built - in spreader you can simply use the 529B on any even surface. The feet are rubber-padded to protect delicate surfaces and have a hole so that the 529B can be screwed to a ladder, apple-box or a sheet of wood.
Bongo Ties 10-Pack
$ 9.95
Bongo Ties 10-Pack
$ 9.95
Bongo Ties 10-Pack
Bongo SKU: A5-01 | Helix SKU: PR6918
Overview
Made with BAMBOO! Patented button-type closure design. Sturdy and Reusable. Ideal for securing unruly cables, cords and radio triggers.
Brilliant Heavy Duty Water Tight Torch Model T-1
$ 4.95
Brilliant Heavy Duty Water Tight Torch Model T-1
$ 4.95
Brilliant Heavy Duty Water Tight Torch Model T-1 - HUP200
Features:
Specifications:
BRNO dri-cap Desiccant Refills
$ 7.95 - Sold Out
BRNO dri-cap Desiccant Refills
$ 7.95 - Sold Out
BRNO dri-cap Desiccant Refills
BRNO SKU: JU2036 | Helix SKU: BRDRIKITGEL
Overview
This is the BRNO dri+Cap Dehumidifying Desiccant Refills Pack 8 [JU2036]
As you know, cameras and lenses, especially modern electronically controlled ones, can be easily-and permanently-damaged by exposure to moisture. Even the condensation that can occur by going from a cool room to a hot outdoors or a cold winter day into a heated house can create condensation on a lens or in a camera. This moisture can lead to fungus or mould damage over time. Humid environments are equally a problem. To solve the problem of humidity/moisture control BRNO has developed their unique dri+Cap protective system that maintains camera bodies and lenses at the proper relative humidity of 35 to 45%. This is accomplished by a colour indicating silica gel in a special packet that does not shed dust particles. the packet is placed in a chamber in the rear of each dri+Cap. The chamber has an O ring to keep the cap seal the cap and not allow the packet to absorb moisture when the cap is not on the item. When attached the dri+Cap has another O ring to keep moisture out of the camera body or lens and to allow the packet to absorb whatever moisture the lens or body has been exposed to. The dri+Cap is supplied in a set for various camera bodies and lenses. Each kit includes a dri+Cap body cap and a dri+Cap rear lens cap plus 8 foil sealed packs of the BRNO colour indicating silica gel
Features:
High quality body and rear caps with 8 packs of foil sealed silica gel.
Silica gel changes colour from orange to deep green as it is exhausted.
Special gel bags do not give off dust particles.
Maintains relative humidity in camera body and lens at 35 to 45%.
O ring seals to keep moisture out of caps.
Caps supplied with moisture proof covers for storage.
Available in:
BRNO dri+Cap Dehumidifying Body/Lens Cap Kit for Canon (JU2030)
BRNO dri+Cap Dehumidifying Body Cap for Canon (JU2031)
BRNO dri+Cap Dehumid
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.0X) Orange
$ 249.20
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.0X) Orange
$ 249.20
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.0X) Orange
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.3X) Orange
$ 249.20
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.3X) Orange
$ 249.20
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.3X) Orange
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.6X) Orange
$ 249.20
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.6X) Orange
$ 249.20
BULK Visible Dust DHAP Sensor Cleaning Swabs (1.6X) Orange
C4-1 Pyrex Flashtube for PM10 and 8050 Heads
$ 92.95
C4-1 Pyrex Flashtube for PM10 and 8050 Heads
$ 92.95
Pyrex flash tube for PM10 and 8050 light heads. Maximum power 400ws.
Calibrite ColorChecker Display Plus
$ 319.00 - Sold Out
Calibrite ColorChecker Display Plus
$ 319.00 - Sold Out
Calibrite ColorChecker Display Plus
MFR SKU: CCDIS3PL | Helix SKU: XRCCDIS3PL
Overview
For profiling OLED, HD and HDR monitors, the ColorChecker Display Plus delivers the ultimate feature set and technology to achieve optimal blacks as well as correct neutral detail levels for more defined shadow details and higher accuracy in dark colours. The included ccProfiler software powered by X-Rite, supports HDR and video workflows while the ColorChecker Display Plus colourimeter has been designed for current and future high-luminance monitors making this the most capable and future proof solution available today. The ColorChecker Display Plus is the ultimate display calibration solution for Creative Perfectionists who demand the most advanced options and maximum control across their creative workflow today and into the future. Editing and colour grading video footage is growing by leaps and bounds and the necessity for accurate colour representation on screen is even more paramount. The only way to edit video accurately is to view your footage accurately. Whether you’re a filmmaker, photographer or both, ColorChecker Display Plus uses advanced technologies to perfect your colour throughout your production and post-production workflow, making sure that what you see is what you’ll get. Now your projected presentations can look the same as your monitor. Build an accurate projector profile in just minutes – it’s as easy as building a monitor profile. The process takes all of the room conditions into consideration – projected colours, screen colour and room lighting – so that you can be confident that your projected images are showing the way you intended.
Features
- Accurately measure luminance/brightness levels up to 2000 nits and BT.1886 default gamma curve – the standard for HDTV
- Black current subtraction technology, especially beneficial on OLED displays or any display that can achieve close to zero black point
- HDR supported displays to minimize clipping in dark area as well as achieve better blacks
- USB-C compatible with included USB-C to USB-A adapter
- Powered by X-Rite
Specifications
Calibrite ColorChecker Display Pro
$ 279.00 - Sold Out
Calibrite ColorChecker Display Pro
$ 279.00 - Sold Out
Calibrite ColorChecker Display Pro
MFR SKU: CCDIS3 | Helix SKU: XRCCDIS3
Overview
The Calibrite ColorChecker Display Pro powered by X-Rite is the ultimate solution for Creative Perfectionists who demand speed, options and flexibility to attain color accuracy. color Perfectionists know that a calibrated and profiled display is a critical element in an efficient digital workflow.
Colour Perfectionists shouldn’t guess when it comes to on-screen colour accuracy. The colour you see on your monitor or projector is the colour you should expect from your printer. Once you take the guesswork and frustration out of calibrating and profiling your displays, you’ll save time and money while gaining full creative control over your images. And now, with the ability to change the colour grading of video footage growing by leaps and bounds the necessity for accurate colour representation on screen is even more paramount. The only way to edit video accurately is to view your footage accurately. With the included video colour standards you can also make sure that what you see is what you’ll get throughout your digital video workflow. Calibrite ColorChecker Display Pro powered by X-Rite incorporates technologically advanced filter and optical systems, amazingly fast measurement speed, and unrivalled colour accuracy on all modern display technologies including LED & Wide Gamut LCDs. It’s also spectrally calibrated, which makes it field upgradeable to support future display technologies. The ultra-modern ergonomic design incorporates three functions – ambient light measurement, monitor profiling, and projector profiling – into a very sleek, compact and fully integrated device with no parts to misplace.
Powerful and easy to use with ccProfiler (or i1Profiler) software
Optical design allows for high repeatability on the same display and across different display types for more consistent color profiling
Rotatable diffuser arm can be used as a stand for table top projector profiling, ambient light measurement and as a cover for instrument optics
Conveniently integrated tripod mount for projector profiling in larger venues
Specifications
Camera / Tripod 1/4-20 Mounting Bracket
$ 10.00
Camera / Tripod 1/4-20 Mounting Bracket
$ 10.00
For tripods, use the threaded insert in the bracket. For cameras, place the socket cap screw in the channel and secure with the larger (3/16) allen key. Loosen the smaller screw in the bracket and slide the bracket onto the battery. Use the smaller (3/32) allen key to lock the bracket.
Camera Lens Step Up Filter Adapter Ring 48mm - 55mm made in Japan
$ 8.70
Camera Lens Step Up Filter Adapter Ring 48mm - 55mm made in Japan
$ 8.70
Here is a high quality, black anodized aluminum Step Up Ring made in JAPAN. This is for mounting a 55mm filter or hood on a 48mm lens front ring. Step up/down rings like this are a good idea. Filters and hoods can be very expensive so these rings save you a lot of money. I like having the ability to use all of my filters and hoods on all of my lenses.
Canon 15 x 50 IS All Weather Binoculars 4625A002
$ 1,349.00
Canon 15 x 50 IS All Weather Binoculars 4625A002
$ 1,349.00
Canon 15 x 50 IS All Weather Binoculars
The Canon 15x50 IS Binocular delivers truly outstanding optical performance and a well-stabilized, high-magnification view. Whether upon the water's edge or high in the upper deck of a stadium, the 15x50 IS will put you right in the middle of the action. The 15x50 IS binocular's great for big game hunters, spectators of the more distant sports such as surfing, or anyone with a hunkering for incredible pulling power which can actually be observed without a tripod. It is a water resistant design with a tripod socket, to allow for easy mounting to tripods or monopods for extended periods of observation.
The 15x50 IS was not designed to be habitually worn around the neck, but if you prefer to carry your optic in this manner then consider a thick neoprene strap instead of the supplied flat woven strap. If you'll be using the binocular in cold weather, it ishighly recommended to use lithium batteries instead of alkaline.
The 15x50 IS is threaded to accept 58mm filters, which is convenient for using polarizers around water, but it also means that during extremely bright or humid conditions you can use a pair of 58mm lens hoods to help shield the objective lenses from dew and stray light (and thus improve contrast).
Image Stabilizer counteracts hand tremors for ±0.7° movement in all directionsField-flattening lens improves edge-to-edge sharpnessUD Ultra-low dispersion glass elementRemarkable close focus distance of 19.7' (6 m) for a 15x power binocularEye relief of 15mm is sufficient for most usersAccepts 58mm filters & lens hoodsStandard 1/4"-20 threaded tripod socket upon bottom of housingBacked by Canon USA's 3-year warranty
Canon 48mm Drop-in
Gelatin Filter Holder II
$ 170.00 - Sold Out
Canon 48mm Drop-in Gelatin Filter Holder II
$ 170.00 - Sold Out
Canon 48mm Drop-in Gelatin Filter Holder II
