DJI SKU: CP.ZM.00000103.02 | Helix SKU: DJCPZM0000010302
With the Ronin-S, DJI just made it truly affordable to mount a DSLR or mirrorless video camera on an effective, versatile single-handed gimbal.
The Ronin-S is an ergonomically designed grip and gimbal with a payload big enough to do the work of independent filmmakers, commercial videographers, and newsroom camera operators, but it’s priced within reach of many advanced amateurs. The gimbal motors are strong enough to handle most DSLR and mirrorless cameras with interchangeable lenses, including zoom lenses and telephotos. It also supports the Manfrotto 501PL type quick-release system, making it compatible with many other tripod and fluid head systems.
The battery life is adequate for a full day—even a long, ambitious day—of shooting. And the Ronin-S itself can be mounted to a tripod, extension pole or radio-controlled buggy. It is compatible with DJI and third-party accessories.
DJI Ronin-S features:
Shake-free video requires two things: a smooth, quality gimbal and a design that lets the camera operator move freely. The DJI Ronin-S has both.
The Ronin-S is equipped with a motorized 3-axis gimbal that stabilizes the camera for pitch, roll and yaw. It even stabilizes while recording quick action. The motors in the gimbal are whisper quiet. The rubberized Ronin-S handle is designed for a secure, steady, one-handed grip, letting the operator move with the action without losing control. The Ronin-S comes with a short tripod that, when closed, doubles as a handle extension for extra-secure two-handed grip, including in flashlight mode.
Because the Ronin-S is compact and balanced, it is easily passed through windows and doorways, over walls, and up or down stairs. It excels in follow work, hoists easily to function as a miniature boom, and works its way through crowds. Shooting inside a vehicle or from the interior? Both just got easier.
The SmoothTrack program further eliminates unwanted movement by enabling the gimbal to compensate for operator movements on the pan, tilt and roll axes. No second operator is needed to input those corrections remotely.
The Ronin-S doesn’t have to be handheld. Mount it to a tripod, a car, an RC buggy, a dolly, a cable, a boom or a jib. When car-mounted, the gimbal motors can function at vehicle speeds up to 46 mph. (If you mount with a device equipped with suction cups, make sure you don’t go beyond the capabilities of the mount.) The Ronin-S also works with the Manfrotto 501PL type quick-release system, which means it will fit any number of available mounts, some of which you may already have.
For more flexible handheld use, a monopod can be attached to allow the camera operator to reach tight spaces with what becomes, essentially, an extended handle. The long monopod also promotes use as a boom or in place of a jib.
A handheld gimbal works best with an ecosystem that provides a range of accessories, and the Ronin-S accepts many. Mount a microphone, lights and an external monitor. Mount a DJI Pro Wireless Receiver and connect wirelessly to DJI Master Wheels and DJI Force Pro for intuitive, precise camera and gimbal movements. Connect third-party remote controllers via the S-Bus port on the Ronin-S.
Five programmable functions make it easy to achieve sophisticated video effects:
No longer will multiple users have to redo settings after every single use by a colleague. Ronin-S remembers settings for up to three users. The settings also can be input to the Ronin-S memory for different conditions or scenes, then activated with the memory button.
The Ronin-S comes standard with a side-mounted focus wheel and a cable to connect the wheel and camera. DJI is working toward pull focus for more models and will make the capability available to more cameras and lenses in continual firmware updates. Here’s where to check compatibility and planned firmware updates.
An external motor also is available from DJI for improved pulled focus.
Just about every popular DSLR and mirrorless digital camera is compatible with the Ronin-S. That includes cameras from Canon, Hasselblad, Nikon, Panasonic and Sony. Firmware updates will continue to expand compatibility for camera models as DJI develops them. The Ronin-S ships with a camera riser for Sony models to make them compatible and with a support to steady long lenses.Sport Mode
To capture especially quick movements, the Ronin-S can be switched to Sport Mode. It’s done simply by pushing and holding the Mode (“M”) button while recording. The camera will change positions more quickly in Sport Mode. Sport mode ends when the button is released.
Auto Tune is accessed from the handle and set up with the app. It allows the operator to adjust the torque of the gimbal motors to suit the scene. Three levels of gimbal motor aggressiveness are available.
Auto Tune also helps to maintain balance, depending on the weight of the camera. Those values can be set manually or set on automatic. When set to automatic, the gimbal motors self-adjust to camera weight. Torque will increase for heavier cameras and lenses, and decrease for lighter setups.
