Ikelite DS-160 Strobe Front Only - Underwater - Ikelite - Helix Camera

Ikelite DS-160 Strobe Front Only $ 599.95 - Sold Out

Quick Shop

Ikelite DS-160 Strobe Front Only

$ 599.95 - Sold Out

Ikelite DS-160 Strobe Front Only - 40602

Ikelite Product Number 4060.2

Product Details

This strobe front is compatible with NiCad, NiMH, and Li-ion battery packs as featured on our DS125 and DS161 strobes. Battery pack sold separately.

The DS160 combines power with wide angle coverage to give you the most bang for your buck.

The quality of light is exceptional due to a round flash tube and custom powder coated reflector designed specifically to deliver the softest, most even coverage possible. Strobes with a straight flashtube may be capable of high powers, but require the addition of a diffuser to spread out their sharp, rectangular beam pattern and reduce the harsh hot spot. The DS160 beam is designed to be perfectly soft and wide spread through its reflector design, and is capable of providing you the coverage and power you want and avoiding the one f/stop loss caused by adding a diffuser.

Both our DS160 and DS161 strobes are legendary for their ability to keep up in rapid firing situations—a cut above any flash on the market. Electrical sync connection and a high-capacity battery pack provide the speed you need to capture fast moving subjects like sharks and sailfish at just the right millisecond.

When combined with a compatible TTL system, the DS160 automatically adjusts brightness to provide perfect exposure whether you're shooting macro, portrait or wide angle. Focus on your camera settings and composition and enjoy the increased number of flashes and even faster recycle time you'll get when working with a TTL system.

A bright, concentrated LED aiming light provides more than enough light for focusing or as a night diving light. The LED turns off and on when the strobe is fired, ensuring that no bright spots will ruin your photo.

The DS160 strobe output is identical to its sister model, the DS161. The DS161 features a built-in 500 lumen video light in place of the DS160's aiming light.

Battery Compatibility

A battery pack is required for operation of this strobe front. Battery pack sold separately. Use only working Ikelite Li-ion (Product Number 4067.2, Product Number 4067), NiMH (Product Number 4066.5), or NiCad (Product Number 4066) battery packs. Please note that older battery packs may not provide optimal number of flashes per charge or recycle times. Use of a flooded or damaged battery pack with this strobe front may cause damage which is not covered by warranty. If you are experiencing problems with your strobe functioning, we recommend trying a new battery pack prior to returning for service.

Our proprietary quick-release toggle system attaches the battery pack with ease and confidence, making a flooded battery virtually impossible. The size of the DS160 is uniquely balanced to its weight to provide near neutral buoyancy in salt water.

What's Included

DS160 strobe front
Diffuser
Waterproof bulkhead cap
Silicone lubricant 1cc tube
2 year limited warranty

Specifications

300 ft (90 m) depth rating
TTL mode with compatible Ikelite TTL systems
Manual power modes in 10 1/2-stop increments
205 lumen LED aiming light
Color temperature 4800K
Guide number 24 m at ISO 100
Coverage angle 90° without diffuser - 100° with diffuser
Over 450 full power flashes per charge (Li-Ion)
Over 225 full power flashes per charge (NiMH)
Up to 3X as many flashes per charge in TTL or fractional powers
Recycle time 1.4 sec or less (Li-Ion)
Recycle time 1.6 sec or less (NiMH)
Ikelite ICS 5-pin bulkhead
Near neutral buoyancy in salt water when used with a li-ion battery pack

Spare Parts

0591.3 Diffuser

0132.36 Battery pack o-ring

9104.5 Waterproof bulkhead cap

Documentation

Instructions (pdf)

View full product details →

Ikelite DS161 Strobe Kit with Sync Cord + Arm / NiMH 4061.35 - UNDERWATER - Ikelite - Helix Camera

Ikelite DS161 Strobe Kit with Sync Cord + Arm / NiMH 4061.35 $ 1,399.95 - Sold Out

Quick Shop

Ikelite DS161 Strobe Kit with Sync Cord + Arm / NiMH 4061.35

$ 1,399.95 - Sold Out

Ikelite DS161 Strobe Kit with Sync Cord + Arm / NiMH

The DS161 combines power with wide angle coverage to give you the most bang for your buck. This kit provides everything you need to add a strobe to any Ikelite TTL system for Compact Digital, Mirrorless, or DSLR camera.

The quality of light is exceptional due to a round flash tube and custom powder coated reflector designed specifically to deliver the softest, most even coverage possible. Strobes with a straight flashtube may be capable of high powers, but require the addition of a diffuser to spread out their sharp, rectangular beam pattern and reduce the harsh hot spot. The DS161 beam is designed to be perfectly soft and wide spread through its reflector design, and is capable of providing you the coverage and power you want and avoiding the one f/stop loss caused by adding a diffuser.

DS160 and DS161 strobes are legendary for their ability to keep up in rapid firing situations—a cut above any flash on the market. Electrical sync connection and a high-capacity battery pack provide the speed you need to capture fast moving subjects like sharks and sailfish at just the right millisecond.

When combined with a compatible TTL system, the DS161 automatically adjusts brightness to provide perfect exposure whether you're shooting macro, portrait or wide angle. Focus on your camera settings and composition and enjoy the increased number of flashes and even faster recycle time you'll get when working with a TTL system.

Specifications

300 ft (90 m) depth rating
TTL mode with compatible Ikelite TTL systems
Manual power modes in 10 1/2-stop increments
500 lumen - 45° LED video light
Color temperature 4800K
Guide number 24 m at ISO 100
Coverage angle 90° without diffuser - 100° with diffuser
Over 225 full power flashes per charge
Up to 3X as many flashes per charge in TTL or fractional powers
Lightning fast recycle time 1.6 seconds or less
Ikelite ICS 5-pin bulkhead
Rechargeable 7.2V 3300mAh NiMH battery pack
Fast 2.5-hour recharge time
Dimensions 3.75 x 7 in (96 x 179 mm)
Weight 2.7 lb (1243 g)
Slightly negative buoyancy in salt water

View full product details →

Ikelite DS51 Underwater Stobe - Underwater - Ikelite - Helix Camera

Ikelite DS51 Underwater Strobe $ 449.95 - Sold Out

Quick Shop

Ikelite Fiber Optic Converter for DS Strobes (3rd Gen) - Underwater - Ikelite - Helix Camera

Ikelite Fiber Optic Converter for DS Strobes (3rd Gen) $ 125.00

Quick Shop

Ikelite Fiber Optic Converter for DS Strobes (3rd Gen)

$ 125.00

Ikelite Fiber Optic Converter for DS Strobes (3rd Gen)

Ikelite SKU: 4401.3 | Helix SKU: 44013

Overview

Converts the electrical bulkhead of any Ikelite DS strobe into a fiber optic port.

Updates

This 3rd Generation of the Fiber Optic Converter features a hard anodized aluminum plug connection which reduces weight without sacrificing durability. It is recommended for use with any Ikelite strobe produced September 2018 or later with a hard anodized aluminum bulkhead.

Like the 2nd Generation model, this Fiber Optic Converter features heightened sensitivity for use with SEA&SEA or Nauticam housings with internal electrical-to-optical flash triggering devices. These devices translate the camera's electrical signals into a series of LED flashes which are much less bright than a traditional built-in camera flash. The Fiber Optic Converter is also compatible with any system where the camera's built-in flash can be seen by a fiber optic cord.

Attachment and Use

The Converter simply attaches to the strobe's electrical bulkhead in place of a sync cord connector. The enlarged slave window provides approximately 90 degrees field of view for remote triggering.

The Fiber Optic Converter automatically configures itself for compatibility with both pre-flash and non pre-flash camera modes. No setting of small switches or confusion over number of pre-flashes. Simply turn on your strobe and take one picture to configure. This adapter is a manual exposure (non-TTL) trigger only. The strobe's output may be adjusted using the manual power settings built into the strobe (varies by model).

An individual Fiber Optic Converter and compatible cord is needed for each strobe. Use of two strobes requires two Fiber Optic Converters.

This converter attaches to an Ikelite DS strobe. It is not intended to be attached to a housing and will provide no functionality if attached to an Ikelite bulkhead in a housing.

Alternatives

There are two shooting scenarios where the High Sensitivity Optical Slave Converter # 4405 would be a better option:

If you're shooting a DSLR or mirrorless camera with Nauticam fiber optic converter and want to shoot at a higher frame rate (4 FPS or faster).
If your primary purpose is to trigger your strobes remotely at a distance from the housing without a fiber optic cable in between.

Strobe Compatibility
